POSEIDON SE7EN+ - Routing the Inflator Hoses

Poseidon SE7EN+ User Manual
Appendix 2
Routing the inator hoses
Connect the O
2
inator hose “marked O
2
” to your onboard O
2
gas supply (or any other
offboard source). Route the hose over your right shoulder and connect to the O
2
inator valve
though the quick connection.
Connect the diluent inator hose to your onboard diluent gas supply (or any other offboard
source). Route the hose over your left sholder and connect to the diluent inator valve though
the quick connection.
The valves described above can be supplied with any other gas supply. E.g. your onboard
oxygen is empty but you have a bailout stage with oxygen or another gas that you would like
to manually add to the loop.
WARNING:
Gas plugged in to the system needs to be selected carefully to
avoid hazardous loop PO
2
.
Figure A2-6. LP hose routing.
Page 87
