PowerLogic PM820 - Page 22

© 2006 Schneider Electric All Rights Reserved
PowerLogic
®
Series 800 Power Meter 63230-500-224A1
Chapter 3—Installation 6/2006
EN–16
ENGLISH
Figure 3 – 2: Clearances for mounting a single power meter
20 (0.787)
20 (0.787)
5
(0.197)
5
(0.197)
106 (4.174)
136
(5.354)
PLSD110047
Figure 3 – 3: Clearances for mounting multiple power meters
mm (in.)
10 (0.39)
92 (3.62)
+0.8
–0.0
92
(3.62)
+0.8
–0.0
HORIZONTAL
PLSD110045
mm (in)
40
(1.57)
92 (3.62)
+0.8
–0.0
92
(3.62)
+0.8
–0.0
VERTICAL
PLSD110046
