© 2006 Schneider Electric All Rights Reserved
PowerLogic
®
Series 800 Power Meter 63230-500-224A1
Chapter 3—Installation 6/2006
EN–20
ENGLISH
Power Meter Without Display
DIN Rail Mounting
1. Refer to “Installation Considerations” on
page EN–13.
2. Place the power meter so that the slot in the
base rests on one edge of the DIN rail and
snap it into place securely.
NOTE: DIN rail mounting is only used to install
power meters that do not have displays (see
Table 1 – 5 on page EN–6 for a list of models).
PLSD11003
