PowerLogic PM820 User Manual

© 2006 Schneider Electric All Rights Reserved
63230-500-224A1 PowerLogic
®
Series 800 Power Meter
6/2006 Chapter 3—Installation
EN–15
ENGLISH
Power Meter With Integrated Display
Dimensions
Mounting
Figure 3 – 1: Power Meter with integrated display dimensions
96
(3.78)
96
(3.78)
69.4
(2.73)
17.8
(0.70)
90.5
(3.56)
20 (0.78)
for each
option module
127.2
(5.01)
109.4
(4.31)
92
+0.8
–0.0
(3.62)
92
+0.8
–0.0
(3.62)
mm (in.)
PLSD110043
DANGER
HAZARD OF ELECTRIC SHOCK, BURN, OR ARC FLASH
• Apply personal protective equipment (PPE) and follow safe
electrical work practices. See NFPA 70E.
• Only qualified workers should install and wire the power meter.
Perform this work only after completely reading the installation
and wiring chapters.
• Turn off all power supplying the power meter and the equipment
in which it is installed before working on it.
• Always use a properly rated voltage sensing device to confirm
that all power is off.
Failure to follow this instruction will result in death or
serious injury.
