Topics Not Covered in This Manual
Some of the power meter’s advanced features, such as onboard data
logs and alarm log files, can only be set up over the communications
link using System Manager
TM
Software (SMS) from PowerLogic. This
power meter instruction bulletin describes these advanced features,
but does not explain how to set them up. For instructions on using
SMS, refer to the SMS online help and the SMS setup guide, which is
available in English, French, and Spanish. See Table 1 – 1 for a list of
power meter models supported by SMS.
NOTE: For additional information, download the reference manual at
powerlogic.com. Select your country > Literature > Meters > Series
800 Power Meter > Instructional > PM800 Reference Manual.
Table 1 – 1: Power Meter Models Supported By SMS
SMS Type SMS Version PM820 PM850 PM870
SMS121 3.3.2.2 or higher
99
—
SMS1500 3.3.2.2 or higher
99
—
SMS3000 3.3.2.2 or higher
99
—
SMSDL
4.0 or 4.0 with Service Update 1
99
—
4.0 with Service Update 2 or higher
999
SMSSE
4.0 or 4.0 with Service Update 1
99
—
4.0 with Service Update 2 or higher
999
SMSPE
4.0 or 4.0 with Service Update 1
99
—
4.0 with Service Update 2 or higher
999
