PowerLogic PM820 - Surface Mount for CM3000;CM4000 Display Retrofit; Replacing Analog Meters

© 2006 Schneider Electric All Rights Reserved
PowerLogic
®
Series 800 Power Meter 63230-500-224A1
Chapter 3—Installation 6/2006
EN–24
ENGLISH
Surface Mount for CM3000/CM4000 Display Retrofit
Replacing Analog Meters
76
[3.000]
54
[2.125]
27
[1.063]
13 [0.500]
4 x Ø4
[Ø0.157]
Ø22 (Ø32 max)
[Ø0.880]
96
[3.780]
10
[0.394]
82
[3.230]
31
[1.220]
mm
[in]
mm
[in]
4 x Ø4
[Ø0.157]
86
[3.376]
86
[3.376]
Ø102
[Ø4.000]
12
[0.457]
96
[3.780]
21
[0.839]
82
[3.230]
19
[0.751]
PM8G
