6 Label Stock
Max Min
Label width 209mm (8.25") 19mm (0.75")
Liner/media width 212mm (8.375") 38mm (1.5")
Label height/length 431mm (17") 13mm (0.5")
Gap between labels 253mm (10") 2.5mm (0.10)
Width of thru-hole 12.65mm (0.5") 6.325mm (0.25")
opening
Distance from edge of 57mm (2.25") 5.06mm (0.20")
media to edge of
thru-hole
Reflective/Black N/A 2.54mm 0.1")
Mark Width*
Max Outer Diameter (OD) 152.4mm (6.0") N/A
Inner Core Diameter (ID) 3.0" (76.2mm) 76.2mm (3.0")
Total Thickness 10 mil (.0010”) N/A
(Liner + Label)**)
Distance from edge of Printer driver assumes 2 mm gap.
media to edge of label However, this is adjustable via the
left margin offset.
* The Reflective/Black Mark should be opaque to infrared light. The mark
should be between the labels. The end of the mark should
correspond with the beginning of the label.
** This is the recommended maximum. There are two factors that
determine whether the printer will accept any particular stock thickness.
1. The ability for the printer to pull the paper through the print area.
2. The ability for the sensor to read through the backing if the
sensor is set to die-cut.
If you are printing in continuous or reflective label sensing mode number 2
does not apply. The fact that the printer must read through the backing in
die-cut mode will limit the thickness much more than the printers ability to
pull the paper through the print area. However, if you adjust opacity level
of the liner enough to allow the label to be seen by the stock sensor, the
thickness will only be limited by the printers ability to pull it through the
printer area. For these reasons the weight or thickness of the liner is a
variable that can not easily be defined. Primera recommends and uses 40#
liner with all label stock. It is important to test all label stock with the
intended printer before ordering large quantities!
