Primes CUBE - Connecting Cube to LDS

35,0(6
Cube
35
Revision 10 EN - 03/2021
14.2 Connect the Cube to the LaserDiagnosticsSoftware LDS
1. Connect the USB cable to the Micro-USB socket on the device and with the PC (see Fig.
9.1 on page18) or activate the Bluetooth function on the PC. When the Bluetooth con-
nection is activated, the USB interface is deactivated.
2. Press the on/off button on the
device.
3. Start the LaserDiagnosticsSoft-
ware LDS.
4. Click on the Devices tab.
5. Click on the + Connect to de-
vice button under the tab.
The Connections window ap-
pears.
6. Click on the desired device.
7. Click on the Connect to device
button.
