13.2 Measuring results display
The last 14measuring values can be read off from the display of the Cube. You can
read off the last 30measuring values with the optional Android™ PRIMES Cube App for
mobile devices or optional LaserDiagnosticsSoftware LDS.
1. Press the on/off button for approx.
2seconds.
The measured laser power (Power) and
pulse duration
1)
(Time) are displayed.
2. Press the on/off button again for 2sec-
onds to have the remaining measuring
values (no.8-14) displayed.
1)
For cw lasers, the average power of the laser
is displayed in W (Power) over the irradiation
duration.
For pulsed lasers, the average power of the
laser is displayed in W (Power) over the cor-
rected burst duration in ms (Time).
