Primes CUBE User Manual

35,0(6
Cube
50
Revision 10 EN - 03/2021
19 Technical data
Measurement parameters Standard absorber
1)
Advanced absorber
1)
Power range 25 – 6000W
2)
25 – 12000W
2)
Wavelength range 900 – 1090nm
Max. beam diameter on the absorber 30mm
Max. power density (peak)
on the absorber (approx.
30mm underneath the
protective window) at
beam diameters
>10mm 1.5kW/cm² 4kW/cm²
10 – 3mm 2.5kW/cm² 5kW/cm²
3 – 1.5mm 5 kW/cm² 10kW/cm²
< 1.5mm 6 kW/cm² 12kW/cm²
Irradiation time 0.1 – 2.0s
2)
(depending on laser power)
Min. on/off times (duty cycle)
for pulsed lasers
50 µs
(e.g. max. 10kHz at 50% duty cycle)
Max. laser rise time 100µs
Energy per measurement 50 – 3000J
Recommended energy per measurement 300 – 500J
Total duration until measurement value
output
<15s
Nominal measurement frequency 300J: 1cycle/min
3000J: 1cycle/15min
Device parameters Standard absorber
1)
Advanced absorber
1)
Max. absorber temperature 120°C
Max. angle of incidence perpendicular to
inlet aperture
±5
°
Max. centered tolerance ±2.0mm
Measuring accuracy at angles of incidence
up to 5°
±3%
Reproducibility ±1%
1)
Please read the information on the identification plate to determine if your device is equipped with a
standard or advanced absorber.
