Primes CUBE - Supply, Communication, and Environmental Data

35,0(6
Cube
51
Revision 10 EN - 03/2021
When nothing is marked, a standard
absorber is built into the device.
When a A marking is made, an advanced ab-
sorber is built into the device.
2)
The stated limit values are to be understood in correlation with the permitted maximum energy
(E
= P∙t).
Supply Data
Power supply Built-in lithium-ion battery
Maximum charging current 1.3A
Voltage 3.7V
Capacity 1000mAh
Energy 3.7Wh
Weight of the battery 20g
Shipment classification Lithium ion batteries contained in equipment
Temperature range for charging the
lithium-Ion battery
0 – 45°C
Communication
Interfaces USB/Bluetooth
Dimensions and Weight
Dimensions (LxWxH) (without connectors) 60 x 65 x 65mm
Weight (approx.) 400g
Environmental Conditions
Operating temperature range 15 – 40°C
Storage temperature range 5 – 50°C
Reference temperature 22°C
Permissible relative humidity
(non-condensing)
10 – 80%
