14.6.2 Display of the measurements stored in the Cube
1. Press the Load measurements
button
• The last 30 measured values
stored in the device are read out
of the memory of the Cube.
2. Switch to the Projects tab.
In the project tree the read out
measured values are displayed.
3. Click on the Power Measure-
ment selection in the drop-down
list below the Toolbench.
The tools Graph, Results Table
and Measurement Value Dis-
play are displayed.
4. Open the desired tool and drag
and drop the measured values
from the project tree into the
opened tool.
