Section 5 Service Procedures
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the dryer(s) before servicing.
• Close gas shut-off valve to gas dryer(s) before servicing.
• Never start the dryer(s) with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the dryer is properly grounded.
W001R1
WARNING
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
(b.) While supporting bulkhead, remove
screws holding bulkhead to rear of
dryer cabinet, and remove assembly
out of dryer. Refer to Figure 58.
(c.) Remove screw holding exhaust duct
to dryer cabinet and pull duct out of
cabinet. Refer to Figure 58.
(d.) Remove two screws from each rear
cabinet top hold-down bracket. Refer
to Figure 61.
(e.) Remove screw holding terminal block
access plate to rear of dryer cabinet
and remove plate.
(f.) Remove wire harness clips.
(g.) Remove locators and screws.
(12) Remove two cabinet top hold-down screws.
Refer to Figure 26.
NOTE: When servicing, cabinet top may be raised
and hinged on the rear hold-down brackets or
supported against wall behind dryer.
(13) Carefully withdraw wire harness through
hole in cabinet top and lift the top off the
rear hold-down brackets.
NOTE: Retainer clips hold the wire harness to the
side panel of the dryer. Remove these before
attempting to withdraw wire harness.
(14) Set cabinet top aside.
(15) Remove two rivets holding gusset and coin
meter bracket to back panel. Refer to
Figure 62.
(16) Remove two screws holding hold-down
brackets to back panel. Refer to Figure 62.
(17) Remove 13 screws attaching back panel to
dryer. Refer to Figure 29. Remove back
panel.
