Printronix P9212 - Setting Shuttle and Counterweight Preload

5–29
Adjustments
1. Captive Screw (2)
2. Cam Cover
3. Screw (6)
4.
Cam Cover Plate
5. Dust Barrier
6.
Force Gauge
7. Counterweight
8.
Feeler Gauge
9. Cam
10.
Right Cam Follower
11. Left Cam Follower
12. Cam Follower Y oke
6
7
8
12
5
10
1
2
4
3
11
9
Figure 5–12. Setting Shuttle and Counterweight Preload
