6–45
Replacement Procedures and Parts
Item Part
Description Notes
1 131152–001 Rear Paper Guide
2 150521–001 Pulley, Paper Feed Collar, Shaft, Alum
140763–002 next to
pulley.
3 102786–610 Screw, Hex w/LW, 6x.62 (2)
4 132312–001 Belt Guard
5 108664–001 Belt, .080P, 103T, .50W
6 108653–001 Splined Shaft Assy
7 102786–605 Screw, Hex w/LW, 6x.31 (2)
8 131158–001 Tractor Shaft Plate
9 102095–002 Tractor Support Shaft
10 134611–002 Tractor Assy, RPF, Right
11 134611–001 Tractor Assy, RPF, Left
12 134424–001 Lever, Platen Reverse
13 141649–001 Belt, Timing,
.080P, 3.8W, 170T
14 134533–001 Cover, Belt, RPF
15 102786–605 Screw, Hex w/LW, 6x.31
16 101526–002 Washer, Flat #6
17 102100–001 Knob, Adjust
18 102185–003 Setscrew
19 101143–002 Left Bushing
20 102094–001 Bushing, Tractor Adjust
21 101547–003 Washer, Flat, Nylon, 1/2 inch
No. Number
To Next Page
