6–47
Replacement Procedures and Parts
Item Part
Description Notes
1 134647–001 Guide, Paper, Machined Remove belt guard before
removing this assy.
2 134646–001 Guide, Paper, Front
3 102559–420 Screw, w/LW 4–40x1.00 (2) Torque: 5 in–lb
4 101526–009 Washer, Flat #4 (2)
5 Ref Red and White leads
6 101867–007 Switch, Snap Action 1.0A, 125 VAC
7 102132–013 Spacer, Round (2) .115/.375x.200 LN
8 104960–001 Nutplate, Switch Mating
9 101554–001 Angle Clip, 90 degree (2)
10 101514–063 Screw, Skt Hd Cap (2) Torque: 11
± 2 in–lb
11 102158–005 Washer, Split Lock #6 (2)
12 101526–002 Washer, Flat #6 (2)
13 134403–001 Side Plate, Left, RPF
14 150452–001 Motor Assy, Stepper No ferrite core used
15 150521–001 Pulley, Paper Feed
16 150707–001 Nut Plate
17 131168–001 Shuttle Motor Assy Ferrite core over red,
blue, and black wires
18 108481–002 Carriage Bolt (4)
19 101526–012 Washer, Flat #1/4 (4)
20 102158–007 Washer, Split Lock, #1/4 (4)
21 101525–010 Nut, Hex, 1/4–20 (4) Torque: 105 in–lb
22 131147–002 Plate, Right Side
23 133673–001 Base Support
24 131301–001 Pickup Assy, Magnetic
25 102788–600 Nut, Hex w/LW, 6–32 (4) Torque: 14 in–lb
26 101526–002 Washer, Flat #6 (4)
27 102158–005 Washer, Split Lock #6 (4)
28 150452–001 Motor Assy, Stepper Ferrite core over all wires
29 101514–063 Screw, Skt Hd Cap (4) Torque: 14 in–lb
30 150834–001 Switch Assy, Paper Detector
31 105728–011 Screw, TF, 6–32x.375 (2) Torque: 5 in–lb
32 140113–003 Screw, 5/16 inch Hex Hd (3) Torque: 20 in–lb
No. Number
