Printronix P9212 - Page 209

6–55
Replacement Procedures and Parts
Item Part
Description Notes
1 101768–003 Belt, Shuttle, T–110
2 101514–041 Screw, Skt Cap, 10x.75
3 102633–001 Bracket, Guide, Mag Pickup
4 101240–001 Magnetic Pickup Arm
5 133673–001 Base Support, Machined
6 132072–001 Oil Wick Assy
7 140133–001 Screw, w/LW (2) Torque: 5 in–lb
8 Part of item 9 Cam
9 131865–002 Flywheel Assy
10 102158–002 Washer, Split Lock #10 (2)
11 101514–042 Screw, Skt Cap, 10x1.00 (2) Torque: 40
± 3 in–lb
No. Number
