6–57
Replacement Procedures and Parts
Item Part
Description Notes
1 150377–002 Control Panel Assy
2 134287–001 Bracket, Control Panel, P9212
3 101526–002 Washer, Flat #6 (4)
4 102786–606 Screw, Hex w/LW,
6–32x.375 (4)
5 150261–001 Fan Assy, 48VDC
6 134478–001 Weldment, Card Cage, P9212
7 134500–001 Cable Assy, Triple I/O
8 Part of item 1 Cable Assy, Control Panel
9 150551–001 Cable Assy, CCB/Mech Dr
10 133750–001 Cable Assy, Hmr Dr/Mech Dr
11 141455–002 Castor, P9212 w/Brake Two front
141455–001 Castor, P9212, w/o Brake Two rear
12 134508–001 Hammer Driver board
13 150855–001 Mechanism Driver board
14 150404–001 Common Controller board
15 133753–001 Cable Assy, Hammer Bank
16 134479–001 Cover, Card Cage, P9212
17 140113–001 Screw, Hex w/Washer (5)
18 202013–001 Dummy Panel, Disk Drive
19 134296–001 Frame/Skin Assy, P9212
20 140113–001 Screw, Hex w/Washer (4)
21 Part of item 1 Cable, Control Panel Assy
No. Number
