3–5
Preventive Maintenance
Ribbon Hub (2)
Right Tractor
Ribbon Mask
Hammer Spring
Lock Tab (2)
Platen
Hammer TIp
Hammer Bank
Ribbon
Deck
Forms
Thickness
Lever
Cover
Screw (3)
Figure 3–2. Cleaning Hammer Bank Assembly
