21
Parameters | Filters
User Manual | Agrónic 2500
Start/Stop a generator set
Stop (000 ... 999”): time that the stop output is activated
(Pa) to stop the diesel pump.
Pump input (000 ... 999”): time between when the
diesel pump is startning and when the ‘Pump 1’ output
is activated. It is used to bring the generator set into
operation before starting the pump.
End of pump (000 ... 999”): time between when the
output of ‘Pump 1’ stops and the diesel pump stops.
Outputs Ar, Pa, Co, Pr: corresponds to the Start, Stop,
Contact and Preheating outputs. If the Agrónic is dual
voltage, these outputs are assigned automatically to
the last four of the unit.
