User Manual | Agrónic 2500
6 INPUT AND OUTPUT CODING
The inputs and outputs are coded in a way that makes it easy to indicate where they are located;
There are five digits in total. The most significant indicates the unit: base, AgroBee or AgroBee-L,
the next two digits for the AgroBee, AgroBee-L module number or internal values and the last
two for the input or output number.
GENERAL OUTPUTS
0: base 00 01 - 27
1: agroBee 01 - 16 01 - 09 Depends on the AgroBee model
3: agroBee-L 01 - 20 01 - 09 Depends on the AgroBee-L model
0 00 00 Description
DIGITAL INPUTS
0: base
00 01 - 12 01 to 10: base
01 01 - 02
01: voltage on the outputs
02: voltage on the solar panel
1: agroBee 01 – 16 01 – 09 Depends on the AgroBee model
2: virtual 00 01
Unique code to indicate that the sensor is virtual.
There can be as many virtual sensors as desired
3: agroBee-L 01 - 20 01 - 09 Depends on the AgroBee-L model
0 00 00 Description
Example
30102: agroBee-L module 1 output 2.
Example
00101: digital input that indicates whether there is voltage on the outputs.
30201: agroBee-L module 2 digital input 1.
