43
Parameters | Installer
User Manual | Agrónic 2500
active schedule in ‘Function - 1.Program’.
• Active period (Yes ... No): with ‘Yes’ it will request
the active period in ‘Function - 1.Program’.
• Activations (Yes ... No): with ‘Yes’ it will ask in
‘Function - 1. Program’ for activations.
• Outside of active hours, end irrigation (Yes ... No):
∙ yes: if the program reaches the end of the
active schedule and has not finished, it
continues with irrigation.
∙ No: if the program reaches the end of
the active schedule and has not finished,
irrigation stops.
• Volume format (00000 m3 | 0000.0 m3 | 000.00 m3)
| (00000 L | 0000.0 L | 000.00 L): when the units are
by volume, this determines the format they will be
entered in.
Fertilization
• Fertilizer type (series | parallel | uniform): indicates
how the fertilizers are injected into the irrigation,
one aer another [series], all at the same time
(parallel) or all at the same time in dierent doses
(uniform).
• Fertilizer units (hh:mm | mm’ ss” | liters | liters/ha):
indicates which fertilizer units will be used: time or
volume. These units are common for all programs.
Irrigation units are configured for each program.
• Stop when cleaning filters (Yes ... No): with ‘Yes’ the
fertilization is temporarily stopped when the filters
are cleaned.
Sectors
• Flow detector. Postpone (00’00” ... 99’59”): when
the sector changes from open to closed, this
unit waits for this time before checking that no
water passes through. When the sector changes
from closed to open, this is the delay time before
checking that water is passing through. Delays
caused by communications if there are modules or
by filling pipes must be taken into account.
Inputs and outputs
• Latch valve (2 wires | 3 wires | 2 w.inv): if the base of
the Agrónic is latch, you can configure what type of
solenoids. If 3-wire is selected, outputs M1 and M2
can be configured as 2-wire latch.
• Latch voltage (12 V | 22 V): the latch trigger voltage
is selected.
• Pump1-Tension latch (12 V | 22 V): latch trigger
voltage for P1.
• Pump1-Latch time (93.7 | 125.0 | 156.2 | 187.5 | 218.7 |
250.0 | 281.2 | 312.5 | 343.7 | 375.0 | 406.2 | 437.5 | 468.7 |
500.0): latch trigger time for P1.
• Pump2-Tension latch (12 V | 22 V): latch trigger voltage
for P2.
• Pump2-Latch time 93.7 | 125.0 | 156.2 | 187.5 | 218.7 |
250.0 | 281.2 | 312.5 | 343.7 | 375.0 | 406.2 | 437.5 | 468.7 |
500.0): latch trigger time for P2.
• Daylight saving time (Yes ... No):
‒ Yes: the controller automatically changes from
winter to summer schedule.
• Digital Meter Sensor Anti-bounce Filter (00.0 ... 10.0):
you can define a time for the back-torque filter for
the base meter inputs (00.0 no filter). This value is the
minimum time that the meter pulse needs to be active
for the total value to increase. A pulse lower than this
time does not increase the total value.
The option of inputs allows reading 4-20 mA or 0-20 V
sensors. The type must be indicated for each input. It must
be related to the switch position on the analog input board.
• Type anal. input 1 (4-20 mA | 0-20 V): select how analog
input 1 will work.
• Type anal. input 2 (4-20 mA | 0-20 V): select how analog
input 2 will work.
• Continuous reading (Yes ... No):
‒ Yes: in latch models, the analog sensors are
powered and read every minute to save power. By
activating continuous reading, the sensors will be
read every second.
5.8.6 Communications
See the ‘Agrónic 2500 Communications’ manual.
5.8.7 Language
The available languages are Spanish, English, French,
Italian, Portuguese and Catalan.
5.8.8 Update software
To update the Agrónic 2500 soware by connecting it
to a PC using a USB cable.
5.8.9 Backup copy
Saves a copy of all the Agrónic parameters and
programs in an internal flash memory. This copy can
be recovered whenever desired, leaving the unit with
the same configuration as when it was saved.
