46
User Manual | Agrónic 2500
ANALOG INPUTS
0: Base
00 01 - 02 4-20 mA inputs. Extension on the base. Option 2 EA
01 01 - 03
01: internal temperature
02: input voltage
03: modem/WiFi RSSI level
02 01 - 04 4-20 mA inputs. Extension on the base. SDI-12 + 4EA option
1: AgroBee 01 – 16 01 – 09
01 to 12: depends on the AgroBee model
13: battery voltage
14: panel voltage
15: rSSI level
16: lQI level
2: Virtual 00 01
Unique code to indicate that the sensor is virtual.
There can be as many virtual sensors as desired
3: AgroBee-L 01 - 20 01 - 09
01 to 13: depends on the AgroBee-L model
14: battery voltage
15: panel voltage
16: radio signal level
4: SDI-12 01 - 08 01 - 24 Depends on the unit model
5: Davis 00 01 - 33 Davis weather station. See the manual for the unit
0 00 00 Description
Example
30713: agroBee-L module 7 analog input 13 (battery voltage).
00201: sDI-12 + 4EA option analog input 1
00002: option 2 EA analog input 2
The sections on Programming,
Manual Actions and
Query are detailed in the
User Manual
r2467 r2469
