CHAPTER 2: Configuring the Thermostat Using the TDI
Table 2-1 describes the thermostat buttons and LCD options.
Each thermostat displays content on the LCD screen. The LCD screen is organized
into primary and secondary (or sub) screens. Most of the Professional Series
thermostats have four primary screens. However, the NT100e/h has three primary
screens. This section describes the primary and secondary screens shown in
Figure 2-2 on page 2-3.
Table 2-1 Thermostat Buttons and LCD Options
Button or LCD Option Description
Up arrow (multiple uses, screen
sensitive)
Increases the setpoint temperature settings. Scrolls up one field
in multi-field screens.
Down arrow (multiple uses,
screen sensitive)
Decreases the setpoint temperature settings. Scrolls down one
field in multi-field screens.
Left button (multiple uses,
screen sensitive)
Selects the function displayed on the LCD.
Middle button (multiple uses,
screen sensitive)
Selects the function displayed on the LCD.
Right button (multiple uses,
screen sensitive)
Selects the function displayed on the LCD.
Left button field Displays the function to be controlled by the left button. In many
screens, this field is labeled Prev and enables you to access the
previous screen.
Middle button field Displays the function to be controlled by the middle button. In
many secondary screens, this field is labeled Select and enables
you to select the highlighted field on the screen.
Right button field Displays the function to be controlled by the right button. In
many screens, this field is labeled Next and enables you to
access the next screen.
