CHAPTER 2: Configuring the Thermostat Using the TDI
Use Table 2-6 to configure the Thermostat Status screen options.
Table 2-6 Thermostat Status Screen Options
Field Description
Reset Press and hold the Reset button for three (3) seconds to perform a software
reboot.
Type Select either Fuel Burner (default) or Heat Pump. When selecting
between either Fuel Burner or Heat Pump or between Heat Pump and
Fuel Burner, the HVAC Mode must be set to OFF prior to selecting the
opposite setting. (See Changing the HVAC Setting (page 2-8) or Status &
Control Page (page 3-9).
Fuel Burner – Fossil fuel systems which includes oil or gas-fired
boilers or furnaces.
Heat Pump SS – Electric heat pump (Single Stage) HVAC system
type.
Heat Pump DS O – Electric heat pump (Dual Stage O Rvs. Valve)
HVAC system type.
Heat Pump DS B – Electric heat pump (Dual Stage B Rvs. Valve)
HVAC system type.
See the Advanced Settings Page (page 3-35) further explanation of the following parameters.
HVAC Type Displays the selected HVAC system type; Fuel Burner or Heat Pump.
Fuel Burner:
Heat Ctrl:
Disable – No heating system is present.
2H – Dual Stage heating is enabled.
1H – Single Stage heating is enabled.
Cool Ctrl:
Disable – No cooling system is present.
2C – Dual Stage cooling is enabled.
1C – Single Stage cooling is enabled.
Heat Pump:
Heat Ctrl:
Disable – No heating system is present (i.e. air conditioning only)
2H – Dual Stage heating is enabled.
1H – Single Stage heating is enabled.
Aux Heat – Auxiliary heat is enabled to augment the heat pump.
Cool Ctrl:
Disable – No cooling system is present (i.e. heat only)
2C – Dual Stage cooling is enabled.
1C – Single Stage cooling is enabled.
To Next Page
