Usage Counters Page
Professional Series Network Thermostat Configuration Guide, Release 3.0 3-55
Part No. 600-01000-200, Rev. 2
Use Table 3-9 to complete the Usage Counter page fields.
Table 3-9 Usage Counters Page Field Descriptions
Field Description
Relay Counters
Heat1 Displays the first stage Heat1 relay minute activity counter. The
Admin account user can reset this field by setting Reset
Counters in the Last Counter Reset field.
Heat2 Displays the first stage Heat2 relay minute activity counter. The
Admin account user can reset this field by setting Reset
Counters in the Last Counter Reset field.
Aux Heat Displays the first stage Aux Heat relay minute activity counter.
The Admin account user can reset this field by setting Reset
Counters in the Last Counter Reset field. Note: This field is
available in heat pump mode only.
Cool1 Displays the first stage Cool1 relay minute activity counter. The
Admin account user can reset this field by setting Reset
Counters in the Last Counter Reset field.
Cool2 Displays the second stage Cool2 relay minute activity counter.
The Admin account user can reset this field by setting Reset
Counters in the Last Counter Reset field.
Fan Displays the Fan relay minute activity counter. Can be reset only
by resetting the Filter Reminder Alarm setting on the General
Settings Page (page 3-14).
External Relay
(NT150e/h and NT160e/h only)
Displays the External Relay minute activity counter. The
Admin account user can reset this field by setting Reset
Counters in the Last Counter Reset field. (See Advanced
Configuration settings on the Advanced Settings Page (page
3-35).)
Counter Status and Control
Include Heat Usage in Fan
Usage
Displays whether to include heating cycle run time in systems
where the fan is used to deliver heat, for example, forced hot air
systems.
 Ye s to include heating cycle run time.
 No to not include heating cycle run time.
Last Counter Reset Displays the date and time of the last manual reset of the Relay
Counters.
 No Action (default)
 Reset Counters – When selected, returns the counters to
zero value (except fan) after clicking Submit.
– mm.dd.yyyy – Date of the last manual reset of the Relay
Counters.
– hh.mm.ss – Time since last the last manual reset of the
Relay Counters.
