Sensor Settings Page
Professional Series Network Thermostat Configuration Guide, Release 3.0 3-47
Part No. 600-01000-200, Rev. 2
Use Table 3-7 to complete the Sensor Settings page fields.
Table 3-7 Sensor Settings Field Descriptions
Field Description
Local Sensor
State Select Enable or Disable to indicate the state of the internal
thermostat thermal sensor. The internal thermal sensor may be
disabled if only remote sensing is desired.
 Disable – The internal thermal sensor is disabled. No Local
Sensor value is displayed on the Status and Control Page
(page 3-9).
 Enable (default) – The internal thermal sensor is enabled.
Sensor Averaging Select Enable or Disable to indicate if the thermostat internal
thermal sensor should participate in the algebraic averaging of
either or both of the Remote Sensors if the Local Sensor is
enabled. (See Zone Temperature (page 3-10).)
 Enable (default) – The internal thermal sensor participates
in the algebraic averaging. The Zone Temperature now
reflects the average temperature of the averaged
measurements.
 Disable – The thermostat internal sensor is excluded from
the thermal averaging calculations.
Sensor Correction Selects a value to adjust the sensor for calibration.
-5
°
F (-2.8
°
C) through +5
°
F (2.8
°
C)
The default is 0.
Remote Sensor 1 and 2
Name Displays the Name (15 characters) for the external thermal
sensor #1/#2.
RS 1 / RS 2
The default is none.
State Select Enable or Disable to indicate if the external thermal
sensor #1 is installed on the thermostat.
 Disable (default) – A remote external thermal sensor is not
connected to the thermostat. No Remote Sensor #1 or #2
value is displayed on the Status and Control Page (page 3-9).
 Enable – A remote external thermal sensor is connected to
the thermostat.
Sensor Type Select the remote sensor type, either thermistor or analog so that
the appropriate temperature translation table is used to calculate
the temperature value. (Consult the Proliphix web site for a list
of sensors available in either type.)
 Thermistor (default) – Thermistor-based thermal sensors.
 Analog – Analog-based thermal sensors.
