Status & Control Page
Professional Series Network Thermostat Configuration Guide, Release 3.0 3-11
Part No. 600-01000-200, Rev. 2
Cool Setting Displays the current temperature programmed for the cooling (A/C) system.
This field is disabled if the HVAC mode is set to Heat or Off. (See HVAC
Mode (page 3-12).) This field is not visible if the thermostat is configured to
be a heat-only controlling device. (See Advanced Settings Page (page 3-35).)
To modify this field, use the drop-down menu to select a Cool Setting.
40
°
F(4.5
°
C) to 99
°
F(37
°
C)
Heat Setting Displays the current temperature programmed for the heating system. This
field is disabled if the HVAC mode is set to Cool or Off. (See HVAC Mode
(page 3-12).) This field is not visible if the thermostat is configured to be a
cool-only controlling device. (See Advanced Settings Page (page 3-35).)
To modify this field, use the drop-down menu to select a Heat Setting.
40
°
F(4.5
°
C) to 99
°
F(37
°
C)
Hold Mode Displays the current state for both the Heat and Cool Setting. To “hold” the
current settings indefinitely or for a prescribed period of time as set on the
Advanced Settings Page (page 3-35), use the drop-down menu and choose
 Hold – Hold mode is enabled.
 Off (default) – Hold mode is disabled.
Schedule Settings
Day Class / Period Displays the current settings for both the scheduled Day Class and Period.
(See Setback Schedules Page (page 3-19).)
Cool Displays the current Cool temperature setting as set within the current Day
Class schedule. (See Setback Schedules Page (page 3-19).)
40
°
F(4.5
°
C) to 99
°
F(37
°
C)
Heat Displays the current Heat temperature setting as set within the current Day
Class schedule. (See Setback Schedules Page (page 3-19).)
40
°
F(4.5
°
C) to 99
°
F(37
°
C)
HVAC Settings
HVAC State Displays the current state of the heating or cooling system. If a state change
is made while viewing this page, click Refresh to update the status.
 Heat – First stage heat is actively heating.
 Heat2 – First stage and second stage heat are actively heating. (Fuel
Burner)
 Aux Ht – First stage and auxiliary heat are actively heating. (Heat
Pump)
 Cool – First stage cool is actively cooling.
 Cool2 – First stage and second stage A/C are actively cooling.
 Off – Neither the heating system or cooling system is active (i.e. on).
Table 3-1 Thermostat Status Field Descriptions (Continued)
Field Description
