CHAPTER 3: Configuring the Thermostat Using the TMI
Firewall Settings
Inbound Port Enter the IP port number to be configured on a local firewall
router to allow inbound WAN traffic access to the thermostat for
remote management.
This feature is used only by the Proliphix Remote Management
Server. The thermostat uses this value, along with the WAN IP
address, to notify the server which port is to be used when the
server wants to contact the thermostat on an internal LAN.
wxyz – (default = 8081) Four digit (max) standard IP port
number designation.
Web Server
HTTP Port Enter the IP port number of the HTTP server within the
thermostat. This field defines the IP port number assigned to the
web server internal to the thermostat for remote access. Note that
if you are trying to access the thermostat’s Web pages, then you
must be able to access the thermostat on this port.
(You must click Submit after changing this parameter to invoke
a software reset to set the new value.)
wxyz – Four digit (max) standard IP port number designation.
The default port number is 80.
LAN Auto-Discovery
Broadcast Port Allows you to specify to which port the thermostat responds to
queries when interrogated by the Device Locator program in the
Proliphix Device Utility tool. The Device Locator Program is a
utility program that allows you to auto-discover the Proliphix
devices on your network.
Security
Table 3-5 Network Settings Field Descriptions (Continued)
Field Description
