Advanced Settings Page
Professional Series Network Thermostat Configuration Guide, Release 3.0 3-41
Part No. 600-01000-200, Rev. 2
Setpoint Differential Establishes the temperature limits above and below the
established setpoint, within which the heating or cooling cycle is
activated and maintained. The anticipator algorithm operates
within this differential range about the setpoint. Optimal comfort
is achieved when this differential is set to 2 (default) or +/- 1°F
about the setpoint. Reduced cycle time is achieved with a larger
differential setting (e.g. 4) or +/- 2 °F about the setpoint. This
feature is most often used with the Max Cycles per hour features
below.
2
°
F (1
°
C)– +/- 1
°
F, (.5
°
C) about the setpoint.
3
°
F (1.5
°
C)– +/- 1.5
°
F, (.75
°
C) about the setpoint.
4
°
F (2
°
C)- +/- 2
°
F, (1.0
°
C) about the setpoint.
5
°
F (2.5
°
C)- +/- 2.5
°
F, (1.25
°
C) about the setpoint.
6
°
F (3
°
C)- +/- 3
°
F, (1.5
°
C) about the setpoint.
Max Cool Cycles/hr Limits the number of cooling cycles every hour. If this value is 3
(default) for example, a cooling cycle can be invoked once in
each of the three 20-minute hourly intervals. In this example, a
subsequent call for cool after the initial cool call in a 20-minute
interval is deferred until the start of the next 20-minute interval.
This feature can be defeated by the user if changes are made to
override the setpoint settings, either at the thermostat or via the
TMI. This feature only applies to scheduled temperature
settings.
Disable – This feature is disabled and unlimited cooling
cycles are allowed.
1-6, 10, 12 – The allowable number of cooling cycles per
hour.
Max Heat Cycles/hr Limits the number of heating cycles every hour. If this value is 5
(default) for example, a cooling cycle can be invoked once in
each of the five 12-minute hourly intervals. In this example, a
subsequent call for heat after the initial heat call in a 12-minute
interval is deferred until the start of the next 12 minute interval.
This feature can be defeated by the user if changes are made to
override the setpoint settings, either at the thermostat or via the
TMI. This feature only applies to scheduled temperature
settings.
Disable – This feature is disabled and unlimited heating
cycles are allowed.
1-6, 10, 12 – The allowable number of heating cycles per
hour.
Table 3-6 Advanced Settings Fields - HVAC Fuel Burner Field Descriptions
Field Description
