Register Designation Type Display / purpose
56 Termination (bus termination) UINT8 0 - DISABLE
1 - ENABLE
2 - IGNORED
57 Software version of the
Modbus module
UINT32 Format: XX.XX.XX.XX
59 Hardware version of the
Modbus module
UINT32 Format: XX.XX.XX.XX
61 Modbus timeout (cyclic
timeout time)
UINT16 0 ... 10,000 ms
63 Modbus Endianness Pattern UINT32 Pattern “0xAABBCCDD” is stored in the pump and
can be read out using this register enabling the
endianness of the Modbus access to be determined
from the master
2.10.3 “Production data pump assembly-specific” register
These register inputs are all only for function code “0x03” (Read
only).
Register Designation Type Display / purpose
200 Version structure definition “Produc‐
tion data” for control assembly
UINT16 Format: XXXX, consecutive version
number
201 10-digit serial number for the con‐
trol assembly
STRING[10] ASCII coding 10 characters
206 Identification tester/test equipment
for control assembly
STRING[4] ASCII coding 4 characters
208 ICT testing date for control
assembly
STRING[10] ASCII coding 10 characters
Date format: DD.MM.YYYY
213 ICT testing time for control
assembly
STRING[8] ASCII coding 8 characters
Time format: HH:MM:SS
217 Production order of service provider
for control assembly
STRING[10] ASCII coding 10 characters
222 Material number of printed circuit
board for control assembly
STRING[8] ASCII coding 8 characters
226 Revision number of assembly: con‐
trol assembly
STRING[2] ASCII coding 2 characters
Hardware version of the assembly
227 Version structure definition “Produc‐
tion data” for power assembly
UINT16 Format: XXXX,
consecutive version number
228 10-digit serial number for power
assembly
STRING[10] ASCII coding 10 characters
233 Identification tester/test equipment
for power assembly
STRING[4] ASCII coding 4 characters
235 ICT testing date for power
assembly
STRING[10] ASCII coding 10 characters
Date format: DD.MM.YYYY
Supplementary operating instructions for Modbus RTU
37
