Manual stop: the pump has been stopped using the
[Start / Stop]
key.
Connection error: If the pump loses its connection to the PRO‐
FINET
®
(as soon as the BUS cable is removed, the bus master is
switched to “Stop” status or the bus master becomes inoperative,
for example), then the error symbol
and the symbol appear.
Error module: If the pump loses its connection to the BUS
module (as soon as the BUS module is removed or if communica‐
tion between the BUS module and pump is interrupted for other
reasons, for example), then the error symbol and the symbol
appear.
4.3.3
LEDs on the PROFINET
®
module
Tab. 37: LED 1 (left) - module operating status
Signal Cause
Off The module has not been initialised.
Green The module has been initialised / normal mode
Green flashing, single flash The module has been initialised and there are diagnostic messages.
Green flashing, 1 Hz DCP flash
Red Serious exception error
Red, single flash Configuration error
Red, double flash IP address error
Red, triple flash Station name error
Red, quadruple flash Internal error
Tab. 38: LED 2 (right) - module status
Signal Cause
Off The module has no supply voltage or connection.
Green The module and the master are exchanging information.
Green flashing The module has been initialised.
4.4 Installation
CAUTION!
IP 65 degree of protection
– IP 65 degree of protection only applies if the
appropriate assembly accessories (cable open‐
ings etc.) have been fitted correctly.
The connection to the existing LAN infrastructure is provided by 2
suitable LAN cables, e.g. twisted pair cable (CAT5 or higher) to
comply with IP 65 with a screwed M12x1 plug, male, 4-pin, D-
coded to IEC 61076-2-101. Complies with IEEE 802.3.
Profinet bus installation
Supplementary operating instructions for PROFINET
®
64
