4
Supplementary operating instructions for PROFINET
®
4.1 Requirements............................................................. 61
4.2 Setting the pump......................................................... 61
4.2.1 General.................................................................... 61
4.2.2
Activating / deactivating PROFINET
®
......................
61
4.2.3
Configuring PROFINET
®
.........................................
62
4.3
Special features in active PROFINET
®
mode............. 63
4.3.1 General.................................................................... 63
4.3.2 Displays................................................................... 63
4.3.3
LEDs on the PROFINET
®
module
........................... 64
4.4 Installation................................................................... 64
4.5 Operation.................................................................... 65
4.5.1 General.................................................................... 65
4.5.2 GSDML file.............................................................. 65
4.5.3 DULCO flex Control DFXa, DFXa data objects....... 66
4.5.4 PLC error and pump behaviour............................... 72
4.1 Requirements
Personnel must be familiar with the contents of the "Operating
instructions for the peristaltic metering pump DULCO flex Control,
DFXa"!
The pump must have the identity code feature "Control type": "E" -
"PROFINET 10". The ‘Fieldbus’ menu item is then available in the
operating menu. (With
‘Fieldbus è active’ , ‘Settings
è PROFINET’ also appears in the operating menu.)
4.2 Setting the pump
4.2.1 General
The pump with PROFINET
®
functionality is set up in the same way
as the standard pump, with the addition of bus functionality.
INFORMATION: The setting process is cancelled in the event of a
pause longer than 60 seconds.
4.2.2
Activating / deactivating PROFINET
®
‘Fieldbus’ must be set to ‘active’ in the operating menu for the
pump to be activated using the PROFINET
®
.
1.
Press the
[Menu] key to access the ‘Menu’ .
ð
The cursor immediately goes to ‘Information’ .
2. Turn the
[Clickwheel] and press it to switch from
‘Information’ to ‘Fieldbus’ .
3. Turn the
[Clickwheel] and press it to switch from ‘Fieldbus’ to
‘inactive / active’ .
Supplementary operating instructions for PROFINET
®
61
