ProMinent DULCO flex Control Supplementary Operating Instructions

Tab. 14: Error table
Error EMCY
Emergency
ErrorCode
Error reg‐
ister
Manufacturer-spe‐
cific Error Field
Component no. Error
type.
Error
class
- -
Level warning 0xFF01 0x81 0x01 0x01 0x01 0x00 0x00
Hose, warning 0xFF01 0x81 0x01 0x04 0x01 0x00 0x00
Temperature, warning 0x4201 0x09 0x01 0x07 0x01 0x00 0x00
Level, error 0xFF01 0x81 0x01 0x21 0x02 0x00 0x00
Memory overflow 0xFF01 0x81 0x01 0x22 0x02 0x00 0x00
Control signal < 4 mA 0xFF01 0x81 0x01 0x23 0x02 0x00 0x00
Control signal > 20 mA 0xFF01 0x81 0x01 0x24 0x02 0x00 0x00
Incorrect metering rota‐
tions
0xFF01 0x81 0x01 0x25 0x02 0x00 0x00
Hose rupture 0xFF01 0x81 0x01 0x26 0x02 0x00 0x00
System error 0xFF01 0x81 0x01 0x2A 0x02 0x00 0x00
Module communication 0x8101 0x11 0x01 0x2C 0x02 0x00 0x00
Module missing 0x8101 0x11 0x01 0x2D 0x02 0x00 0x00
Tab. 15: Emergency ErrorCodes from the stack
Emergency
ErrorCode
#define ERRCODE_COMM_ERROR 0x8100 Communication error
#define ERRCODE_CAN_OVERRUN 0x8110 CAN overrun
#define ERRCODE_CAN_PASSIVE 0x8120 CAN in error passive
#define ERRCODE_HB_ERROR 0x8130 HB or life guard
#define ERRCODE_CAN_RECOVER_BOFF 0x8140 CAN recovered from bus-off
#define ERRCODE_BAD_PDOPARA 0x8210 PDO not processed due to length
#define ERRCODE_BAD_PDOLEN 0x8220 PDO length exceeded
1.7.6 Explanations of objects
The ‘DeviceState’ object contains current operating statuses and
the pump's pending errors. 'DeviceState' is read-only.
DeviceState [Index 0x2A10, Subindex
0x00]
Supplementary operating instructions for CANopen
21
