Register Designation Type Display / purpose
2203 “Warning threshold cont.
mode” level monitoring
UINT8 With continuous level monitoring:
Specification of a threshold value (as a [%] of the
maximum liquid level); if this threshold value is not
reached, a warning is generated by the level monitor
0 … 100%
2204 “Error threshold cont. mode”
level monitoring
UINT8 With continuous level monitoring:
Specification of a threshold value (as a [%] of the
maximum liquid level); if this threshold value is not
reached, an error is generated by the level monitor
0 … 100%
2205 “Liquid level unit” level moni‐
toring
BOO‐
LEAN
This setting enables the continuous level measure‐
ment unit to be selected
0 - LEVEL DATA AS A % (RELATIVE TO THE MAX‐
IMUM)
1 - LEVEL IN LITRES (ABSOLUTE FIGURE)
2206 “Total volume of tank” level
monitoring
UINT16 Specifies the capacity of the tank containing the feed
chemical
1 … 65535 l
2.10.10 “Debug data” register
These register inputs are all only for function code “0x03” (Read
only).
Register Designation Type Display / purpose
3002 Hose type UINT8 Information about the hose fitted
0 - TPV, 5 bar (Pump type 0530, SP)
1 - TPV, 7 bar (Pump type 0730, SP)
2 - PUR, 5 bar (Pump type 0530, VP)
3 - 0518 hose (18 l/h at 5 bar), VP
4 - 0565 (65 l/h at 5 bar), VP
3003 Current rotor position UINT8 Under certain conditions, a progress bar appears on
the display, which shows the position of the rotor
3014 Fan speed UINT16 Rotations / second
3017 Power supply to the Modbus
assembly
UINT16 Power supply to the Modbus assembly
3018 CAN connection error UINT16 0 - CAN connection OK
1 - CAN node not found
2 - Vendor ID is incorrect
3 - Product code is incorrect
4 - Modbus register version is incorrect
Supplementary operating instructions for Modbus RTU
47
