Chapter 3 Software
PA-6225 SERIES USER MANUAL
Page 211
MEMORY MAP
ASSIGNMENT
0xE00000D0-0xE00000DB
Intel
®
Sideband Fabric Device
0xFF000000-0xFFFFFFFF
Intel
®
82802 Firmware Hub Device
0xA0000-0xBFFFF
PCI Express Root Complex
0xA0000-0xBFFFF
Intel
®
HD Graphics
0xC0000-0xDFFFF
PCI Express Root Complex
0xE0000-0xFFFFF
PCI Express Root Complex
3-7-2. PB-6822RC
Interrupt Map
IRQ
ASSIGNMENT
IRQ 1
Standard PS/2 Keyboard
IRQ 19
Standard AHCI 1.0 Serial ATA Controller
IRQ 19
PCI standard PCI-to-PCI bridge
IRQ 0
System timer
IRQ 8
High precision event timer
IRQ 4294967294
Intel
®
Celeron
®
Processor J1900
IRQ 4
Communications Port (COM1)
IRQ 3
Communications Port (COM2)
IRQ 7
Communications Port (COM3)
IRQ 10
Ethernet Controller
IRQ 10
Communications Port (COM4)
IRQ 23
Standard Enhanced PCI to USB Host Controller
IRQ 16
PCI standard PCI-to-PCI bridge
IRQ 22
High Definition Audio Controller
IRQ 17
PCI standard PCI-to-PCI bridge
IRQ 81
Microsoft ACPI-Compliant System
IRQ 82
Microsoft ACPI-Compliant System
IRQ 83
Microsoft ACPI-Compliant System
IRQ 84
Microsoft ACPI-Compliant System
IRQ 85
Microsoft ACPI-Compliant System
