Page #17 background image
Sterling 10 Installation Manual
RINS1413-1 Page 13
3. TECHNICAL SPECIFICATIONS
ZONES
PGM OUTPUTS
Number of programmable zones – 8 Number of programmable outputs – 2
Zone loop type – Normally Closed Output types 3 for PGM1, 2 for PGM2
Zone loop current – 0.76mA to 1.03mA PGM1 – Transistor Open Collector, 200mA @12V
Zone loop timers – 0.35 sec. (0.035 sec.) PGM2 Transistor Open Collector, 10mA @12V
Zone activation resistance – not less than 2kOhm
CURRENT CONSUMPTION
Sterling 10 PCB (alone) – 130mA
POWER SUPPLY
LCD Remote keypad – 100mA
Power input – 17V AC ICON Remote Keypad – 60mA
Low voltage output
13.8V DC regulated
FUSE CONTROL
BATTERY
Auxiliary supply output
1A (quick blow F1L) Type – Lead Acid rechargeable
Bell supply output – 1A (quick blow F1L) Battery Capacity
2.8A/h … 7.2A/h
AC supply input – 2A (quick blow F2L)
Battery input – 2A (quick blow F2L)
ENVIROMENTAL
Mains input – 250mA
Operation temperature: 0 to +40
º
C (+32 to +104
º
F)
Storage temperature: -20 to +40
º
C (-4 to +172
º
F)
This product complies with TS50131-3:2003 and is suitable for use in
EN50131-6:1998 systems at security grade 1, environmental class 2.
UK = Suitable for use with systems installed to PD6662:2004 (AMD)
EXPORT = Suitable for use with systems installed to EN50131-1
