Q-See QT SERIES User Manual

14
PICTURE 2-5
REC
Exit MENU
PIP ZOOM
Search
INFO
ENTER
Next SEQMulti
1
10 1211 13
2 4
6
8
5
7
9
3
# Button Function
1 Menu
Open Main menu
2 REC Begin recording
3 Search
Opens up video search
window
4 Exit Exits menu or interface
5
Direc-
tional
Controls
Move cursor
Control PTZ direction in
PTZ mode
6 Enter Confirms choice
7 PiP Picture-in-Picture mode
8 Zoom Activates digital zoom
9
Play-
back
Controls
Play/Pause, Stop,
Fast Forward, Rewind,
Single Frame Forward/
Backward
10
Multi-
Screen
Choose multi-screen
display mode
11 Next
Switch to next live view
group
12 Info Opens DVR Info menu
13 SEQ
Switch to sequential
channel display

Q-See QT SERIES Specifications

General

Series	QT Series
Video Compression	H.264
Remote Viewing	Yes
HDMI Output	Yes
VGA Output	Yes
Motion Detection	Yes
Channels	4, 8, 16
Recording Resolution	1080p, 720p
Hard Drive Capacity	Up to 6TB
Mobile App Support	Yes
Network Connectivity	Ethernet
