30
4.1 BASIC CONFIGURATION
This chapter is intended to help you get your DVR up and running before you activate any
advanced features which are covered in later chapters. You can use the mouse, remote
control and the buttons on the front of the DVR to operate your system, but for convenience,
we will be discussing operations using the mouse. Information on P.T.Z. cameras and alarms
will be found in their own chapters, Chapters 7 and 8, respectively.
MENU NAVIGATION
Navigation through the user interface is point and click. Double-clicking on an icon within a
given menu will open that menu, or a submenu. The Main Menu is the starting point to reach
all of the DVR’s settings and features. Selecting the Menu icon on the left of the Control Bar
or pressing the Menu button on the DVR and remote control open the Main Menu.
MAIN MENU SETUP
CHAPTER 4
PICTURE 4-2
PICTURE 4-1
Clicking on any icon will open the relevant
menu.
SETUP
From the Setup menu select the Basic menu
by clicking on its icon.
PICTURE 4-3
Main Menu
NOTE! When configuring your settings, you will always need to click Apply to save your
current settings before closing the window with Exit otherwise your changes will be lost.
You may click Exit or the close window box (X) in the upper right of the window to close
without saving changes but an alert will pop up asking if you wish to save changes. Click
OK to save changes or Cancel to continue without saving. You may select the Default
button to restore your settings to those set at the factory.
