45
4.8 FILE SEARCH, PLAYBACK AND MANAGEMENT
Access the recordings on the DVR, play them back and backup the recordings to an external
storage device.
NOTE! Throughout this window, if the screen resolution is VGA 800*600,
the time search interface will show a Hide button. Clicking on this button will
expand or minimize the entire interface as needed.
Four submenus appear in this section: Time
Search, Event Search, File Management
and Image.
TIME SEARCH
Search for an event within a range of dates and times.
PICTURE 4-33
PICTURE 4-34
Select which channel you wish to search and the screen display mode. The Calendar icon in
the Start Time window allows you to select a start date. Highlighted dates indicate that there
is recorded data for those days.
The vertical column of numbers to the left of the grid are the available channels. The horizontal
headings are blocks of time within the day.
You can select which time to begin the review by entering it in the start time window or clicking
on the time grid and moving the yellow line to the approximate start time.
Clicking on the PLAY button will begin the playback from the time selected. It will also bring up
a playback toolbar allowing finer control of the playback process.
Previous
Record
Play/
Pause
Stop Fast
Forward
Rewind Screen Display
Mode
Volume
Hide
Tool Bar
ExitFrame
Advance
Next
Record
Playback
Progress Bar
Zoom Color
Trim Backup
Playback
Speed
>>1 X08/19/2011 12:02:00
PICTURE 4-35
