34
Spot Tab
This allows select feeds to be viewed on a separate monitor that is connected to the DVR but
may be in another room, for example. There will be no menu access on this auxiliary display.
PICTURE 4-10
PICTURE 4-11
PICTURE 4-12
Only one channel can be displayed at a time
on this monitor. You may create groups of
channels or designate a single channel as
a group. A channel may be placed within
more than one group. Select the order of the
channels and their dwell time. Use the left and
right arrows to switch between groups.
Mask Tab
Set up masks on individual cameras to block out select areas on each screen. This is to grant
privacy in situations when other users may be able to view the camera feeds and you wish to
restrict viewing of certain areas or activities.
Click on the Setting button next to a given
camera to apply a mask to its view.
Up to three areas may be masked in an
image. Simply click and drag to cover the
area. To delete, double-click on a mask.
Right-click to exit the screen, your masks will
be saved.
The masks will appear on that channel’s
image in the live area as well as on
recordings.
