STEP 4. Connect the power and data
cables. Press firmly, but do not
force them onto the pins or you may
damage them. The connectors are
“keyed” to ensure they are connected
in the proper position.
STEP 5. Attach hard drive to the base of
the DVR with screws using the four
mounting holes.
STEP 6. Replace the DVR cover and
secure.
DATA
CABLE
POWER
CABLE
HARD DRIVE
HARD DRIVE
MOUNTING HOLES
FOR HARD DRIVE
PICTURE 9-3

Q-See QT SERIES Specifications

General

Series	QT Series
Video Compression	H.264
Remote Viewing	Yes
HDMI Output	Yes
VGA Output	Yes
Motion Detection	Yes
Channels	4, 8, 16
Recording Resolution	1080p, 720p
Hard Drive Capacity	Up to 6TB
Mobile App Support	Yes
Network Connectivity	Ethernet
