Parameter QT5032 QT5132 QT5140
COMPRESSION Compression
Format
Standard H.264 Baseline
VIDEO Video In Composite 1.0V
p-p/75Ω,
BNC x 32
Composite 1.0V
p-p/75Ω,
BNC x 32
Composite 1.0V
p-p/75Ω,
BNC x 4
Video Out COMPOSITE 1.0V p-p/75Ω, BNC x 1, VGA x 1, HDMI
x 1
VGA Resolution 1280x1024, 1024x768, 800x600, HDMI
Record
Resolution
NTSC:
352x240,
704x480
960x480 (960H)
PAL: 352x288,
704x576
960x576 (960H)
NTSC: 352x240, 704x480
PAL: 352x288, 704x576
Display Frame
Rate
(per camera)
704x480 at 30FPS
Record Frame
Rate
(per camera)
NTSC:
960H & D1 30
FPS
CIF 30FPS
PAL:
960H & D1
25FPS CIF
25FPS
NTSC:
D1 30 FPS
CIF
30FPS
PAL:
D1 25FPS CIF
25FPS
NTSC:
960H & D1 30
FPS
CIF 30FPS
PAL:
960H & D1
25FPS CIF
25FPS
AUDIO Audio Input -8dB~ 22k,
RCA X16
-8dB~ 22k, RCA
X4
-8dB~ 22k,
RCA X2
Audio Output -8dB~92dB, RCA X1
ALARM Alarm Input NO or NC 16CH None
Alarm Output 4CH 1CH None
STORAGE Record Mode Manual/Sensor/Timer/Motion Detection
Multi-Function Multiplex
INTERFACE Network
Interface
RJ45 (LAN, Internet)
Communication
Interface
eSATA x2
RS485,
USB 2.0 x 2
(One for
Backup, One
for USB Mouse)
RS485,
USB 2.0 x 2 (One for Backup, One
for USB Mouse)
CONTROLS PTZ Control Yes
Remote Control Yes
DISK INFO Disk Type SATA x 8 (up to
3TB each)
SATA x 2 (up to
3TB each)
SATA x 1 (up to
2TB each)
OTHER INFO Voltage 110/230V 12V4A 12V2A
Optimal
Temperature
50°F to 104°F 10°C to 40°C
10% to 90% Humidity
Power Use
w/o Hard Drive
42W
40W 5W

Q-See QT SERIES Specifications

General

Series	QT Series
Video Compression	H.264
Remote Viewing	Yes
HDMI Output	Yes
VGA Output	Yes
Motion Detection	Yes
Channels	4, 8, 16
Recording Resolution	1080p, 720p
Hard Drive Capacity	Up to 6TB
Mobile App Support	Yes
Network Connectivity	Ethernet
