Parameter QT5440 QT5516 QT5616
COMPRESSION Compression
Format
Standard H.264 Baseline
VIDEO Video In Composite 1.0V
p-p/75Ω,
BNC x 4
Composite 1.0V p-p/75Ω,
BNC x 16
Video Out COMPOSITE 1.0V p-p/75Ω, BNC x 2, VGA x 1, HDMI
x 1
VGA Resolution 1280x1024, 1024x768, 800x600, HDMI
Record
Resolution
NTSC:
352x240,
704x480
960x480
PAL:
352x288,
704x576
960x576
NTSC: 352x240,
704x480
PAL: 352x288,
704x576
NTSC:
352x240,
704x480
960x480 (960H)
PAL: 352x288,
704x576
960x576 (960H)
Display Frame
Rate
(per camera)
704x480 at 30FPS
Record Frame
Rate
(per camera)
NTSC:
960H & D1 30
FPS
CIF 30FPS
PAL:
960H & D1
25FPS CIF
25FPS
NTSC: 30FPS PAL: 25FPS
AUDIO Audio Input -8dB~ 22k,
RCA X2
-8dB~ 22k, RCA X4
Audio Output -8dB~92dB, RCA X1
ALARM Alarm Input None NO or NC 16CH
Alarm Output None 1CH
STORAGE Record Mode Manual/Sensor/Timer/Motion Detection
Multi-Function Multiplex
INTERFACE Network
Interface
RJ45 (LAN, Internet)
Communication
Interface
RS485,
USB 2.0 x 2 (One for Backup, One for USB Mouse)
CONTROLS PTZ Control Yes
Remote Control Yes
DISK INFO Disk Type SATA x 1 (up to
2TB each)
SATA x 1 (up to 3TB each)
OTHER INFO Voltage 12V2A 12V3A
Optimal
Temperature
50°F to 104°F 10°C to 40°C
10% to 90% Humidity
Power Use
w/o Hard Drive
5W 18W

Q-See QT SERIES Specifications

General

Series	QT Series
Video Compression	H.264
Remote Viewing	Yes
HDMI Output	Yes
VGA Output	Yes
Motion Detection	Yes
Channels	4, 8, 16
Recording Resolution	1080p, 720p
Hard Drive Capacity	Up to 6TB
Mobile App Support	Yes
Network Connectivity	Ethernet
