4 – Installation
Installing a Switch
59096-02 C 4-7
A
If you are using the 10-Gbps ports, remove the port covers by the cover tabs using
your fingers or pliers as shown in Figure 4-4.
Figure 4-4. Removing 10-Gbps Port Covers
To install XPAK switch stacking cables, position the cable connectors with the
circuit board toward the mid line of the respective switch faceplates as shown in
Figure 4-5. When installing the 3-inch XPAK switch stacking cable, insert the
cable connectors into the 10-Gbps ports at the same time.
Figure 4-5. Installing XPAK Switch Stacking Cables
CAUTION! To maintain proper air flow and prevent the switch from
overheating, keep covers installed in unused 10-Gbps ports.
A
L
A
L
A
LA
16
L
A
17
L
A
18
L
A
19
L
A
L
AL AL AL
ALA
L
A
L
A
LA
16
L
A
17
L
A
18
L
A
19
L
A
AL
ALA
L
A
L
A
LA
16
L
A
17
L
A
18
L
A
19
L
A
Circuit Board
