4 – Installation
Installing a Switch
59096-02 C 4-23
A
4.2.8
Configure the Switch
You can configure the switch using the SANsurfer Switch Manager application or
the command line interface. To configure the switch using SANsurfer Switch
Manager, click the Open Configuration Wizard radio button in the Initial Start
dialog, then click the Proceed button. The Configuration wizard explains and
prompts you for the following configuration information:
To configure the switch using the command line interface, do the following:
1. Open a command window according to the type of workstation and
connection:
Ethernet (all platforms): Open a Telnet session with the default switch
IP address and log in to the switch with default account name and
password (admin/password).
telnet 10.0.0.1
Switch Login: admin
Password: *******
Temporary IP address
Temporary subnet mask
Archive template file
Switch domain ID (1–-239)
Domain ID Lock (Locked/Unlocked)
Switch name
Permanent IP address
Permanent subnet mask
Permanent gateway address
Permanent network discovery method
Date and time
Admin account password
Create a configuration archive?
NOTE: Refer to Table B-9 through Table B-16 for information on factory
configuration default values.
