104 QXS G2 Hardware Installation and Maintenance Guide
Connecting Two 2U Systems (2-Host Ports) for Replication (Multiple
Servers/Switches/Locations)
Figure 92 provides an illustration of connecting two 2U12/2U24 RAID chassis (storage systems) for
replication (multiple servers/switches/two locations).
Figure 92 Connecting Two 2U Systems (2-Host Ports) for Replication (Multiple
Servers/Switches/Locations)
Connecting Two 5U Systems for Replication (Multiple Servers/Switches)
Figure 93 provides an illustration of connecting two 5U84 RAID chassis (storage systems) for
replication (multiple servers/switches/two locations).
Figure 93 Connecting Two 5U Systems for Replication (Multiple Servers/Switches)
NOTE: The diagrams shown in Figure 91 and Figure 93 represent two branch offices cabled to
enable disaster recovery and backup. In case of failure at either the local site or the remote site, you
can fail over the application to the available site.
RAID Chassis RAID Chassis
I/O Switch I/O Switch
To Host Servers
(Site A)
To Host Servers
(Site B)
Ethernet WAN
