LTE-A Module Series
EM120R-GL&EM160R-GL Hardware Design
EM120R-GL&EM160R-GL_Hardware_Design 13 / 79
Support 3GPP R9 DC-HSDPA, HSPA+, HSDPA, HSUPA and WCDMA
Support QPSK, 16QAM and 64QAM modulation
⚫ DC-HSDPA: Max 42 Mbps (DL)
⚫ HSUPA: Max 5.76 Mbps (UL)
⚫ WCDMA: Max 384 Kbps (DL)/384 Kbps (UL)
Internet Protocol Features
⚫ Support PPP/QMI/NTP*/TCP*/UDP*/FTP*/HTTP*/PING*/HTTPS*/
SMTP*/MMS*/FTPS*/SMTPS*/SSL* protocols
⚫ Support the protocols PAP (Password Authentication Protocol) and
CHAP (Challenge Handshake Authentication Protocol) usually used
for PPP connections
Text and PDU mode
Point to point MO and MT
SMS cell broadcast
SMS storage: ME by default
Support (U)SIM card: 1.8/3.0 V
Support Dual SIM Single Standby*
⚫ Compliant with USB 3.0 and 2.0 specifications, with maximum
transmission rates up to 5 Gbps on USB 3.0 and 480 Mbps on USB
2.0.
⚫ Used for AT command communication, data transmission, firmware
upgrade, software debugging, GNSS NMEA sentences output and
voice over USB*
⚫ Support USB serial drivers for:
Windows: 7/8/8.1/10
Linux: 2.6/3.x/4.1–4.15
Android: 4.x/5.x/6.x/7.x/8.x/9.x
Comply with PCI Express Specification, Revision 2.1 and support 5 Gbps
per lane
Used for AT command communication, data transmission, firmware
upgrade, software debugging, GNSS NMEA sentences output
EM160R-GL
Provide Main, Rx-diversity/GNSS, MIMO1 and MIMO2 antenna connectors
EM120R-GL
Provide Main and Rx-diversity/GNSS antenna connectors
Support LTE/WCDMA Rx-diversity
Gen9 Lite of Qualcomm
Protocol: NMEA-0183
Compliant with 3GPP TS 27.007, 27.005 and Quectel enhanced AT
commands
Size: 42.0 ±0.15 mm × 30.0 ±0.15 mm × 2.3 ±0.1 mm
Weight: approx. 6 g
Operation temperature range: -25 °C to +75 °C
1)
