LTE-A Module Series
EM120R-GL&EM160R-GL Hardware Design
EM120R-GL&EM160R-GL_Hardware_Design 60 / 79
5.3. Antenna Installation
5.3.1. Antenna Requirements
The following table shows the requirements on Main, Rx-diversity/GNSS and MIMO antennas.
Table 31: Antenna Requirements of EM160R-GL
Type
Requirements
Supported Bands
Main Antenna
(Tx/Rx)
VSWR: ≤ 2
Efficiency: > 30%
Max Input Power: 50 W
Input Impedance: 50 Ω
Cable Insertion Loss: < 1 dB
(699–960 MHz)
Cable Insertion Loss: < 1.5 dB
(1710–2200 MHz)
Cable Insertion Loss: < 2dB
(2300–2690 MHz)
LTE:
B1/B2/B3/B4/B5/B7/B8/B12/B13/
B14/B17/B18/B19/B20/B25/B26/
B28/B29/B30/B32/B38/B39/B40/
B41/B42/B43/B46/B48/B66
WCDMA:
B1/B2/B3/B4/B5/B6/B8/B19
Rx-diversity/
GNSS Antenna
VSWR: ≤ 2
Efficiency: > 30%
Max Input Power: 50 W
Input Impedance: 50 Ω
Cable Insertion Loss: < 1 dB
(699–960 MHz)
Cable Insertion Loss: < 1.5 dB
(1559–2200 MHz)
Cable Insertion Loss: < 2 dB
(2300–2690 MHz)
LTE:
B1/B2/B3/B4/B5/B7/B8/B12/B13/
B14/B17/B18/B19/B20/B25/B26/
B28/B29/B30/B32/B38/B39/B40/
B41/B42/B43/B46/B48/B66
WCDMA:
B1/B2/B3/B4/B5/B6/B8/B19
GNSS:
GPS;
GLONASS;
BeiDou/Compass;
Galileo
MIMO1 Antenna
（Rx）
VSWR: ≤ 2
Efficiency: > 30%
Max Input Power: 50 W
Input Impedance: 50 Ω
Cable Insertion Loss: < 1 dB
(699–960 MHz)
Cable Insertion Loss: < 1.5 dB
(1559–2200 MHz)
LTE:
B1/B2/B3/B4/B7/B25/
B30/B32/B38/B39/B40/B41/B66
