Quectel LTE-A Module Series User Manual

LTE-A Module Series
EM120R-GL&EM160R-GL Hardware Design
EM120R-GL&EM160R-GL_Hardware_Design 59 / 79
1)
LTE-FDD B29/32 and LTE-TDD B46 support Rx only and are only for secondary component carrier.
5.2. GNSS Antenna Connector
The following table shows frequency specification of GNSS antenna connector.
Table 30: GNSS Frequency
LTE B43
3600–3800
3600–3800
MHz
LTE B46
1)
5150–5925
5150–5925
MHz
LTE B48
3550–3700
3550–3700
MHz
LTE B66
1710–1780
2110–2200
MHz
Type
Frequency
Unit
GPS/Galileo
1575.42 ±1.023
MHz
GLONASS
1601.65 ±4.15
MHz
BeiDou/Compass
1561.098 ±2.046
MHz
